1.The structure is strong and durable, bearing large load, smooth movement and low noise.
2.It is controlled by microprocessor, which is stable and reliable and easy to integrate.
3.The barrier machine can be combined with other equipment to realize automatic control.
4.In the case of power failure or malfunction, such as a barricade machine in a rising state need falls, you can cover by manual operation will be rising barricade machine back to horizontal position so that the traffic.
5.Adopt the international leading low pressure hydraulic drive technology, the whole system is high security and reliable and stable.
6.Remote control device: it is remote controlled by remote control, and can be installed in the area more than 30 meters from the controller.
| System control | Electro-hydraulic control |
| Allowed pressure to pass | More than 100 tons of container vehicles are allowed to pass |
| Power supply | 220V/380V(The control voltage24V) |
| System power(W) | 1.5KW/2.2KW/3KW/4kw |
| Rise time | <=8S(Can be adjusted) |
| Fall time | <=8S(Can be adjusted) |
| Working temperature | -35℃~75℃ |
| Storage environment | -10℃~65℃Rainproof and moisture-proof |
| texture | A3 steel, spray anti-rust primer |
| color | Multiple colors (optional) |
| The body size | 2000mm-6000mm*1050mm*580mm |
| Rising height | 450/600(It can be customized according to actual requirements) |
Waterproof and dustproof grade | IP68 |
| customization | |
