Model

SJY1.3-1

Bearing capacity

1000KGS

Minimum height

380mm

Maximum height

1300mm

Base Platform size

1800*600mm

Ball platform size

1500*1000mm

Lifting speed

80mm/s

Intelligent control handle

Forward and backward switch; Low speed and high speed 2 gear; Horn warning; Both sides can control lifting; Power display function.

Rechargeable battery

（12V100AH, quantity 2）

Charger input voltage

Single-phase AC220V 50HZ/CUSTOM

Drive system

Hydraulic

Control mode

Intelligent control handle+Wired handle

Hydraulic oil cylinder

1PCS, set the length as required

Platform ball

Stainless steel plate set 50mm spacing of the ball

Material

Low carbon steel

wheel

1 universal wheels 2 directional wheels2 stabilizing training wheels

Safety facilities

① Smart handle anti-collision retreat, ② oil valve on sealing parts,  ③ overload protection,④ phase protection in control box,⑤ emergency stop button on control box, ⑥ emergency falling device on hydraulic system with power cut off
